Hospital Phlebotomy Finding Difficult Veins Infrared IV Infant Vein
Viewer Price
The vein illuminator detects veins beneath the skin by using
infrared light, then projecting the image of the veins on the skin
surface directly above the veins. Qualified medical personnel can
observe the displayed vasculature to find a vein of the right size
and the location of superficial veins for venipuncture and other
medical procedures. The vein illuminator only shows superficial
vasculature. The maximum depth of displayed veins varies by
patients. Vein finder is a portable model of the vein illuminator.
Vein finderis lightweight and equipped with high-capacity
rechargeable lithium battery. Medical staffs can hold it easily to
assess and locate the patient’s vascular. For convenient operation,
different types of support can be chosen to fix Vein finder.
Intended Use
The vein illuminator/finder/viewer is a portable instrument to help
medical professionals to locate certain superficial veins. The vein
illuminator/finder/viewer should not be used as the sole method for
locating veins,
and should be used by a qualified medical professional. When using
the vein illuminator, medical practitioners should always follow
the appropriate medical protocols and practices which are required
by their medical facility, to exercise sound medical judgment.
The vein illuminator can be used in the situation that the
determination of vein location is necessary.
When used properly, the vein illuminator enables users to locate
certain superficial veins in connection with medical procedures,
such as venipuncture.
Specification
| Weight (the imaging unit) | 450 g (battery included) |
| Dimensions (the imaging unit) | 240*60*60 mm |
| Accuracy | 0.25 mm |
| Light type | Near-infrared light |
| Infrared wavelengths | 850 nm |
| Image resolution | 720*480 |
| Visable vein size | ≥ 1 mm |
| Depth of visable vein | ≤ 12 mm |
| Best projection distance | 200 ± 20 mm |
| Image frame rate | 20 FPS |
| LED lifetime | 20000 hours |
| Power supply | DC 5V, ≤ 3.5W |
| Battery | Replaceable, Li-Ion, 3.7V, 4400mAh |
| Battery working time | ≈ 5 hours |
| Charging time | ≈ 3 hours |
| Voltage | AC 100-240V, 0.4-0.6A, 50-60HZ |
| Operating mode | Handheld or Suspension |
| Operating temperature | + 10 ℃ to 30 ℃ |
| Workplace stress | 700hPa to 1060hPa |
| Working humidity | 0-90%(non-condensing) |
| Storage humidity | 0-90%(non-condensing) |
| Storage temperature | 0 ℃ to 60 ℃ |
Application Type
• Target vein quike finding: Helpful for finding the target veins
efficiently and easily
• Guidance for venipuncture: Provide a more clear vein view,
Indicate the vein position, trend, branch, crossing
• Vein evaluation: Evaluate the vein filling condition
• Aesthetic medical injection: Helpful for medical staffs to avoid
the veins
• Feeder vein treating: Helpful for finding more feeder veins and
treat throughly, make the feeder treating visible.
Application Department
Pediatrics
- Small veins
- Baby fat
- Anxiety of the children and their families
Oncology
- Fewer options for successful access because of repeated infusions
and procedures and medication
Radiology
- Limited viable patient access
- Should puncture the big and straight veins
Plastic Surgery
- Sclerotherapy for treating spider telangiectasia
- Cosmetic injections on the face
- Increasing petient satisfaction
Vascular Surgery
- Sclerotherapy for treating spider telangiectasia
- Vein stripping treating
Applicable Patient
• Fat patients
• Edema patients
• Dark skin
• Infants
• Children
• Old patient
• Plastic Surgery
• Vascular Surgery
Color: 5colors adjustable,for different patient complexions and personal
preferences.
Inverse:Allows clinicians to highlight the veins or highlight the
surrounding tissue,for reducing the interference of complexions,
density of hairfollicles and room brightness.
Brightness:3 degrees of brightness being adjustable, allowing clinicians
customizing image brightness based on the environment light.
Size:3 kinds of image sizes, for pediatric patients or the
situation only nee to focus on one vessel.
Enhanced Mode:Helpful for finding the smaller or deeper veins.
Operation
1. Power button: Switch on/off, Standby mode/ wake
2. Color button: Change displayed color 5 colors, for different
patient skin tone and personal preference
3. Size button: Adjust image size, 3 sizes, for pediatric patients
or when need to focus on only one vessel.
4. Inverse button: Switch dark and bright pattern, Reduce the
interference of skin tone, density of hair follicles and room
brightness.
5. Mode button:
Adjust brightness 3 degrees, allow clinicians customizing the image
brightness base on the environment light;
Change mode Normal and Enhanced, Enhanced mode is useful for
finding the deeper or smaller veins.
Caution:
When held directly overhead, the vein illuminator accurately
locates the center of a vein.
The width of displayed veins may differ from the actual width, due
to the physical differences of patients and the width of veins. But
the center line of the vein is accurate.
The vein illuminator is portable internally powered by battery and
approved for continuous operation.
The vein illuminator is not protected from ingress of water.
No training is required to operate the vein illuminator.
The vein illuminator requires no routine or preventative
maintenance.
