2015 New CE Approved LCD Screen Microcirculation
Microscope Capillary microcirculation
Blood microcirculation:
1. Model XW880(7inch/8inch color LCD)
2. For health care&beautiful industry
3 Independent research and development ability
4. nailfold microcirculation microscope is a noninvasive health
diagnostic device
Technical parameters:
Microscope Magnification | ≥400 times |
Built-in camera pixels | 380000 pixels |
Light source | LED |
Brightness of the light source | ≥ 600cd/m2 |
Stage | X-Y double layer compound mechanical stage |
nailfold microcirculation microscope monitor | colar LCD monitor 8inch(4:3) |
Input&Output | AC input 100~240V 50/60Hz DC output DC12V,2A |
Microscope Package | Aluminum box( Size 34*29*20cm)
|
Features:
1.in 5 seconds can be observed in the microvascular circulation,
simple operation and fast;
2.the microscopic image is stable, clear, do not shake;
3.400 times the microcirculation of a dedicated high-resolution lens of the microscope;
4.handheld ultra-light design, so that the observation of more
mobility;
5.with micro-focus wheel, free to adjust the focus length, the use
of more convenience
6.lens built-in LED cold light source, accurate projection illumination on an object;
7.using non-invasive way, to observe the microcirculation of human
body in time;
8.observing the microcirculation for any part of human body.
Application:
1. nail wall distal microcirculation observation
2. cutaneous distal microcirculation observation
3. tongue microcirculation observation
4.the auricle distal microcirculation observation
5.lips microcirculation observation
6.the other parts of the microcirculation observed
7.sweat glands observed
8.hair follicles observed
9.bamboo charcoal commodity microcirculation efficiency testing
10.far- infrared commodity microcirculation efficiency testing
11. the germanium titanium micro-circulation of goods performance
detection
12.ore commodity micro-cycle efficiency detection.
How to use:
step1: Put a little cedar oil daub on the nails and cuticles need
to be test
step2: Put the finger in the slot, and then adjust the focal length
and position
step3: Looking for blood vessel and to observe
Shape of blood vessel ansa :
(1) Normal shape likes the hair clip , exceptionally for
overlapping and abnormal, the overlapping proportion number should
not surpass 30%, the abnormal should not surpass 10%
(2) abnormal blood vessel:
1st, the blood vessel of heart and brain disease, the diabetes, the
desmosis and so on, with contract whole body disease or the partial
fungus infection and flesh wound and other organization disease is
easy to appear the blood vessel to be abnormal
2nd, when arteriosclerosis, diabetes with serious abnormal , and
the proportion excessive highly.
3rd, collagen disease, Reynold sickness, neurosis, the variation of
blood vessel increases.
Blood vessel ansa’s periphery
After has carried on the shape and the fluid state observation, but
also
should carry on the observation to the periphery condition:
1.Seeps out: refers to, in the blood vessel, appears the phenomenon
for the blood plasma ingredient excessively permeability blood pipe
wall and the accumulation in blood capillary’s periphery , is one
of common micro circulation changes. Characteristic: The blood
vessel ansa periphery gap expands, and bright; The blood vessel
ansa’s image is fuzzy, the length reduces.
2.Hemorrhage: phenomenon for the red blood cell leaves to the blood
vessel outside .
Should distinguish the hemorrhage which the flesh wound or other
non- pathogenesis factor creates, if the leakage hemorrhage, the
main reason is blood capillary wall damage, causes the permeability
hyperfunction and the blood flow changes and so on .
